High Performance Connectivity
Conformity Europe.
Compliant Product.
Compliant Product.
Rated Product.
5 YR Industrial Warranty.
| Insulator Material | PA66/POM/PA66 GF15%, Black | Shell Material | Brass & Zinc Alloy, NI Plated |
| Contact Material | Phosphor Bronze (C5191-H) | Sealing | Silicone Rubber TSE 2186U |
| Underplate | 50µ” to 150µ” NI | Contact Area | 10µ” AU |
| IDC Area | 80µ” to 150µ” SN Plated | Protection Grade | IP67 |
| Operating Voltage | 48V (per contact) | Current Rating | 0.5A (per contact) |
| Contact Resistance | ≤5 mΩ | Insulation Resistance | ≥100 MΩ MIN @ 500 VDC |
| Dielectric Withstanding | 500 VAC / Minute | Temperature Range | -40°C to +90°C |
| Cable Diameter | 6.2mm to 8.4mm | Conductor Size | 24 to 26 AWG |
| Standards | IEC 61076-2-109 | Performance | 10GBase-T (XG® Systems) |
| RoHS Conformity | Yes | CE Marking | Yes |
As a member of the HDBaseT® Alliance, DTECH® products comfortably support the latest HDBaseT standards — engineered for next-gen homes and buildings.
Built for residential, commercial and industrial environments, DTECH XG® system architecture guarantees full 10GbE performance from end to end.
