High Performance Connectivity
Conformity Europe.
Compliant Product.
Compliant Product.
Rated Product.
5 YR Industrial Warranty.
| Coupling | Threaded | Rated Voltage | 60V AC/DC |
| Termination | Soldering | Rated current | 0.5A |
| Coding | X | Contact resistance | ≤5 mΩ |
| Pollution degree | 3 | Insulation resistance | ≥100 MΩ |
| Temperature range | -40°C to +80°C | Shell Material | Copper nickel plated |
| Protection Grade | IP67 | Contact material | Copper Gold plated |
| Mating cycles | ≥500 | Insert material | PA66+GF UL94 black |
| Cable outlet diameter | 8.0mm Max | Sealing | NBR |
| Performance | 10GBase-T (XG® Systems) | Conductor Size | 24 to 28 AWG |
| Standards | IEC 61076-2-109 | RoHS Conformity | Yes |
| CE Marking | Yes |
As a member of the HDBaseT® Alliance, DTECH® products comfortably support the latest HDBaseT standards — engineered for next-gen homes and buildings.
Built for residential, commercial and industrial environments, DTECH XG® system architecture guarantees full 10GbE performance from end to end.
