High Performance Connectivity
Conformity Europe.
Compliant Product.
30 YR System Warranty.
Euroclass 50575.
| Fibre Mode | OM4 Multimode | Fibre Count | 8 |
| Fibre Type | Loose Tube | Tube Configuration | 1 × 8F |
| Loose Tube Gel | Thixotropic Compound | Strength Members | Glass Yarns |
| Armouring | Corrugated Steel Tape | Environment | Direct Burial |
| Jacket Material | LSZH UV Stabilized | Ripcords | 2 Under Sheath |
| Fibre Colour Code | TIA-598-D | Outer Diameter (mm) | 8.1 ± 0.5 |
| Weight/km (±15%) | 84 kg | Operating Temp | -20 to +70°C |
| Max Tensile Load | 500N | Crush Resistance / 10cm | 1000N |
| Min Bend Radius Installation | 20 × OD | Min Bend Radius Installed | 15 × OD |
| Proof Stress | ≥8.4N (100Kpsi, ≥1.0%) | Attenuation at 850nm | ≤3.5 dB/km |
| Attenuation at 1300nm | ≤1.5 dB/km | Bandwidth at 850nm | ≥3500 MHz.km |
| Bandwidth at 1300nm | ≥500 MHz.km | Numerical Aperture (NA) | 0.200 ± 0.015µm |
| Core Diameter | 50 ± 2.5µm | Cladding Diameter | 125 ± 2.0µm |
| Core / Clad Concentricity | ≤1.5µm | Cladding Non-Circularity | ≤2.0% |
| Euroclass | Eca | Standards | IEC 60793-1, IEC 60793-2, IEC 60794-3-10 |
| RoHS Conformity | Yes | CE Marking | Yes |
| Cable Length | Custom | Packaging Method | Reel |
As a member of the HDBaseT® Alliance, DTECH® products comfortably support the latest HDBaseT standards — engineered for next-gen homes and buildings.
Built for residential, commercial and industrial environments, DTECH XG® system architecture guarantees full 10GbE performance from end to end.
