High Performance Connectivity
Conformity Europe.
Compliant Product.
30 YR System Warranty.
In-House Tested.
Insertion & Return Headroom.
Euroclass 50575.
| Fibre Mode | OM3 Multimode | Fibre Count | 4-24 |
| Fibre Type | Tight Buffered | Strength Members | Glass Yarns |
| Environment | Internal / External | Jacket Material | LSZH UV Stabilized |
| Ripcords | 2 Under Sheath | Fibre Colour Code | TIA-598-D |
| Outer Diameter (mm) | 6.6 | Weight/km (±15%) | 45 kg |
| Operating Temp | -20 to +70°C | Max Tensile Load | Short term: 660N / Long term: 200N |
| Crush Resistance / 10cm | 1000N | Min Bend Radius Installation | 20 × OD |
| Min Bend Radius Installed | 15 × OD | Proof Stress | ≥8.4N (100Kpsi, ≥1.0%) |
| Attenuation at 850nm | ≤3.5 dB/km | Attenuation at 1300nm | ≤1.5 dB/km |
| Bandwidth at 850nm | ≥1500 MHz.km | Bandwidth at 1300nm | ≥500 MHz.km |
| Numerical Aperture (NA) | 0.200 ± 0.015µm | Core Diameter | 50 ± 2.5µm |
| Cladding Diameter | 125 ± 2.0µm | Primary Coating Diameter | 250µm |
| Core / Clad Concentricity | ≤1.5µm | Cladding Non-Circularity | ≤2.0% |
| Reaction to Fire (EN 13501-6) | Cca | Smoke Development (EN 13501-6) | s1a |
| Flaming Droplets (EN 13501-6) | d0 | Acidity (EN 13501-6) | a1 |
| Standards | IEC 60793-1, IEC 60793-2, IEC 60794-3-10 | RoHS Conformity | Yes |
| CE Marking | Yes | Cable Length | Custom |
| Packaging Method | Reel |
As a member of the HDBaseT® Alliance, DTECH® products comfortably support the latest HDBaseT standards — engineered for next-gen homes and buildings.
Built for residential, commercial and industrial environments, DTECH XG® system architecture guarantees full 10GbE performance from end to end.
