High Performance Connectivity
Rated Product.
Conformity Europe.
Compliant Product.
5 YR Industrial Warranty.
| Connector A | RJ45 | Connector B | RJ45 |
| Connector Layout | 8 Pin (4 Pins Terminated) | Enclosure Material | Polycarbonate |
| Connector Plating | 50µ Gold | Shielded | Shielded |
| Mating Durability | 500 Times | Cable Outlet | 180° cable outlet |
| PoE | PoE++ | Strain Relief Boot | Yes |
| RoHS Conformity | Yes | Number of Pairs | 4 |
| Conductor Material | Bare Stranded Copper | Conductor Construction | 7/0.20 ± 0.008 |
| Insulation Material | Foamed PE | Insulation Thickness (mm) | 0.25 |
| Insulation OD (mm) | 1.32 ± 0.05 | Binder Material | Mylar Tape |
| Shielding | S/FTP | Shielding Material | Al/Mylar Tape |
| Shielding Overlap | 35% | Braid Material | Aluminium Magnesium Alloy Wire |
| Braid Construction | 16/8/0.12 ± 0.008 | Braid Coverage | 80% |
| Jacket Material | PUR | Jacket Thickness (mm) | 0.80 |
| Jacket OD (mm) | 8.0 ± 0.3 | Insulation Spark Test (20°C) | 2.50kV |
| Conductor Resistance Max (20°C) | 87.6 ohm/km | Insulation Resistance | 100 MΩ·km |
| Data Transmission | 1000Base-T | Standards | ISO 11801 Class Ea / ANSI/TIA-568.D |
| CE Marking | Yes |
As a member of the HDBaseT® Alliance, DTECH® products comfortably support the latest HDBaseT standards — engineered for next-gen homes and buildings.
Built for residential, commercial and industrial environments, DTECH XG® system architecture guarantees full 10GbE performance from end to end.
